ENVE - FOUNDATION AM30 WHEELS

The AM30 Carbon Wheel is your one-wheelset quiver for lunch laps, park laps, and backcountry epics. With a modern rim shape, compliant-yet-snappy carbon laminate, tubeless optimization, anti-pinch flat technology, a 30mm internal width, lifetime guarantee, and a balanced all-mountain ride-tune, the AM30 is ready for anything you can throw at it.

• 30 mm inner-rim width
• Innerdrive Foundation Hub
• Sapim Race spokes and Alpina brass locking nipples
• Moulded spoke and valve holes ensure fibre continuity, increasing strength
• Wheelset weight: 1880g including valves and tape
• Rated for trail, enduro, and e-bike use

E-MTB READY

Approved for use on all electric drive systems, the AM30 will instantly upgrade the handling of your e-bike. The INNERDRIVE hub’s oversized ratchet and bearing system handles the added demands of e-assist, delivering reliable performance and long-term durability.

ALL-MOUNTAIN RIDE TUNE

With a unique shape and ride-tune, the AM30 balances compliance and vibration damping for all-day comfort, while retaining quick cornering, acceleration, and gravity-rated strength. Offset spoke holes balance spoke tensions to help preserve the wheels’ quickness and the spoke’s integrity – despite the rim’s additional compliance.

INNERDRIVE FOUNDATION HUBS

INNERDRIVE™ represents the pinnacle of bicycle drive mechanisms. Oversized steel ratchets are positioned inboard and over the bearings reducing stress on the axle and bearings while ensuring positive and reliable engagement.

• 100% ENVE Designed oversized 42mm ratchet drive system
• Longer bearing life
• Reduced axle stress = less bearing drag and prolonged bearing life
• Drive component retention
• Perfect Preload – automatic preload adjustment
• Low maintenance & easy serviceability

WIDE HOOKLESS BEAD AND MOULDED SPOKE HOLES

Potholes and unforeseen impacts are part of life, but that doesn’t mean they need to ruin your ride. The AM30 features ENVE’s Wide Hookless Bead, which is a design element at the leading edge of the rim that dissipates impact energy and reduces the likelihood of pinch flatting your tubed or tubeless tyre.

Tubeless performance depends on the tire maintaining a light press-fit with the rim on the bead seat diameter. ENVE chooses a hookless tubeless rim profile as it allows the rim’s critical tolerance at the bead seat diameter to be both consistent and accurate. In short, hookless is chosen to deliver a safer and more reliable tubeless system.

ENVE’s patented process of molding spoke and valve stem holes results in rims that are stronger and lighter. Because carbon fiber gets its strength from continuous fibers, ENVE routes the fibers around the hole without cutting them, increasing the strength of each spoke hole. Because of this process, our spoke holes are capable of maintaining higher spoke tensions, greatly reducing the risk of spoke pull-through and the need to constantly true your wheels. Strong, light, and maintenance-free.

SPECIFICATIONS

DIAMETER: 29" | 27.5" Rear/29" Front
INNER RIM WIDTH: 30mm
HOLE COUNT: 28h/28h
HUB: ENVE Innerdrive Foundation
SPOKES: Sapim Race
NIPPLES: Alpina Brass Locking
DRIVETRAIN: XDR, MS
RECOMMENDED TYRE WIDTH: 2.3" - 2.6"
WHEELSET WEIGHT: 1880g (29") | 1823g (29"/27.5")

WE'VE GOT YOUR BACK

ENVE Products are designed so that you can ride and race with confidence. As a member of the ENVE family, we’ve got your back. If something goes wrong, we are committed to do everything in our power to keep you rolling. Please click here for detailed information about ENVE's  Incidental Damage Policy and Factory Warranty
